What is 100TPD Rice Mill Plant?

This 100t/day complete rice milling machine includes the whole process from rice cleaning machine to rice packing machine. It can get 4-5ton final rice from paddy rice. It contains a full set of rice processing machines like the paddy rice cleaner machine, rice destoner machine, rice huller machine, paddy rice separator machine, rice mill machine, rice polisher machine, rice color sorter machine, rice packing machine, and rice elevators.

The goal of a rice milling system is to remove the husk and the bran layers from paddy rice to produce whole white rice that is sufficiently milled free of impurities and contains a minimum number of broken rice. Hongjia Rice milling machines are designed and developed from superior-grade raw materials in compliance with international quality standards.

The 100ton/day complete rice processing plant is designed to produce high-quality rice. Meticulously tested on various quality parameters under the guidance of our experienced professionals, this large-scale complete rice processing line is recognized for its reliable performance, less maintenance, longer service life, and enhanced durability.

We can also design the milling line according to the different requirements of different customers. We can consider using vertical type rice whitener or horizontal type rice whitener, normal manual type husker or pneumatic automatic husker, different quantities on silky polisher, rice grader, color sorter, packing machine, etc., as well as suction type. You may contact us and advise your detailed requirements so we can design the plant for you according to your requests.

What is 100T/D Complete Rice Mill Plant Working Process?

The 100T/D complete rice mill project can process paddy into national standard rice just in one process at the following flow chart: Raw material feeding-Vibrated cleaner & Destoner → Rice Husker→Paddy Rice Separator → Rice Mill →Rice Polisher → Rice Grader→ Rice Color Sorter → Packing, Then the rice can be on market for sale.

What Is The Structure of the 100T/D Complete Rice Mill Plant?

Our 100T/D complete rice mill project is a fully automatic rice production line, which includes the entire process from paddy cleaning, stone removal, rice hulling, rice separating, rice milling, rice polishing, and rice color sorting, rice grading, and final rice packaging. You no longer need any other machines, you can realize the entire processing from paddy rice to the final finished white rice. Therefore, this complete set of rice milling equipment is very popular. Welcome, contact us for the details.

The Modern Rice Milling System Consists of:

Hopper: feeding raw paddy material to the rice mill machine;

Combined paddy cleaner & de-stoner: other light impurities such as dust and debris, block, the stone should be removed as much as possible to reach a better cleaning effect;

Rice husker: remove husk from paddy;

Rice separator: it is mainly used for separating brown rice from paddy making use of their differences in specific gravity and friction coefficient in three parts: paddy, brown rice, and a mix of both;

Rice mill machine: the rice whitening machine is developed for rice whitening, which is an advanced technology of the world rice mill whitener at present to make rice temperature down, bran content less, and broken increment lower;

Rice polisher: polishes the rice surface by spraying water, which facilities the formation of a smooth gelatinous layer that prolongs the preservation time. Extended polishing chamber to produce high-quality rice;

Rice grading machine: the rice grader can sieve milled rice efficiently and accurately into several classes: head rice, large broken, medium broken, small broken, etc;

Rice color sorter: the rice color sorting machine is used to sort bad, milky, Chalky, Paddy, and foreign materials. The CCD signal while blanking is been tested. If it is found that there are unqualified rice or impurities in the materials, the ejector will blow the defective goods in the hopper;

Rice packing machine: this rationed automatic weighing packing machine consists of a material box, a packing scale, a sewing machine, and a conveyor belt. It can cooperate work with all the model's rice mill production lines, and also for the packing bags capacity can choose 1-50kg per bag for your needs;

What Are The Features of the Automatic 100TPD Rice Mill Plant?

1. Hongjia 100TPD integrated rice mill plant can be used to process both long-grain rice and short-grain rice(round rice), suitable to process both white rice and parboiled rice, high output rate, low broken rice rate;

2. Multi-pass rice whiteners will reduce broken rice rate and make the product rice appearance more beautiful, and more suitable for commercial rice milling; customers can also choose vertical type rice whitener;

3. Equipped with separate drum cleaner, pre-cleaner, and de-stoner, higher efficiency on impurities and stones removal;

4. Equipped with a mist polisher, can make the rice silkier and crystal;

5. It uses a negative pressure motor to remove dust and collect husk and bran, effectual and environmental-friendly. The bag-type dust collector or pulse dust collector is optional and suitable for customers with higher local requirements for environmental protection;

6. Having perfect technological process flow and complete machines for cleaning, stone removing, husking, rice milling, white rice grading, polishing, color sorting, automatic scaling, and packing;

7. Having a high automation degree and realizing continuous full automatic operation from paddy feeding to product rice packing;

8. With a strong technical supporting team, can customize suitable machine configurations according to customers’ requirements. We can design the whole rice mill project for customers, including the factory building and the machine layout. We have a professional after-sales service team in Africa who can help you with machine installation and plant commissioning;
